RAL 5011 Steel Blue – Polyarmor®G17 Thermoplastic (Spray)

Thermoplastic Powder Coating. Highly Durable Plastic Coating for Spray Application.

A functionalized polyethylene co-polymer thermoplastic powder coating designed for maximum mechanical performance, impact resistance and UV stability. Polyarmor® G17 is a very durable coating for outdoor applications.

Electrostatic Deposition:

This product can be applied via electrostatic deposition with or without pre-heat. When not using pre-heat, the powder should be applied to achieve a thickness of 8 – 12 mils (203 – 305 micron). Recommended gun setting when using Corona equipment is 10 – 20 µA or 40 – 60 kV. Post-heat at 350 – 425 °F (177 – 218 °C) for 5 – 15 minutes depending on metal thickness, or until desired flow out is achieved. For preheated parts, the recommended preheat temperature is 400 °F (204 °C). Deposit 8 – 12 mils (203 – 305 micron) or higher if desired. For improved surface finish, parts may be post-baked for a short period of time if necessary. Times and temperatures in the oven will depend on configuration and thickness of the part.

No Cure Time:

Thermoplastic powder coatings need only be heated enough to flow out the coating, nothing more. Overheating may cause degradation or embrittlement of the coating. Coating may be put into service when cooled.

Please refer to Polyarmor® G17 Technical Data Sheet for further detailed information. PDF Download
